S-Plastics Ultem ATX100 resin is Higher impact, high flow Polyimide blend. ECO Conforming, UL94 HB Listing.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 68 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 80 | % | ASTM D 638 |
| Flexural Stress, yld, 2.6 mm/min, 100 mm span | 106 | MPa | ASTM D 790 |
| Flexural Modulus, 2.6 mm/min, 100 mm span | 2530 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 2082 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 427 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 157 | °C | ASTM D 648 |
| Relative Temp Index, Elec | 115 | °C | UL 746B |
| Relative Temp Index, Mech w/impact | 115 | °C | UL 746B |
| Relative Temp Index, Mech w/o impact | 115 | °C | UL 746B |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.21 | - | ASTM D 792 |
| Mold Shrinkage, flow, 3.2 mm | 0.5 - 0.7 | % | S-Plastics Method |
| Melt Flow Rate, 295°C/6.6 kgf | 6 | g/10 min | ASTM D 1238 |
| ELECTRICAL | Value | Unit | Standard |
| Hot Wire Ignition {PLC) | 1 | PLC Code | UL 746A |
| High Ampere Arc Ign, surface {PLC} | 0 | PLC Code | UL 746A |
| Comparative Tracking Index (UL) {PLC} | 3 | PLC Code | UL 746A |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| UL Recognized, 94HB Flame Class Rating (3) | 0.76 | mm | UL 94 |
| CSA (See File for complete listing) | LS88480 | File No. | CSA LISTED |
| Source GMD, last updated:01/11/2000 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 135 | °C |
| Drying Time | 4 - 6 | hrs |
| Drying Time (Cumulative) | 12 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 330 - 355 | °C |
| Nozzle Temperature | 325 - 350 | °C |
| Front - Zone 3 Temperature | 330 - 355 | °C |
| Middle - Zone 2 Temperature | 320 - 345 | °C |
| Rear - Zone 1 Temperature | 310 - 330 | °C |
| Mold Temperature | 95 - 135 | °C |
| Back Pressure | 0.3 - 0.7 | MPa |
| Screw Speed | 40 - 70 | rpm |
| Shot to Cylinder Size | 40 - 60 | % |
| Vent Depth | 0.025 - 0.076 | mm |
| Source GMD, last updated:01/11/2000 | ||
|
