S-Plastics Ultem HU2410 resin is 40% Glass fiber filled, enhanced flow Polyimide (Tg 217C). ECO Conforming. For medical devices and pharmaceutical applications.Healthcare management of change, biocompatible (ISO 10993 or USP Class VI), food contact compliant.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 186 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 179 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 2.5 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 2.5 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 11720 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 254 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 11430 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 180 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 180 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 2 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 2 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 11500 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 240 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 10000 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 427 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 112 | J/m | ASTM D 256 |
| Izod Impact, notched, -30°C | 114 | J/m | ASTM D 256 |
| Instrumented Impact Total Energy, 23°C | 18 | J | ASTM D 3763 |
| Izod Impact, notched 80*10*4 +23°C | 10 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -30°C | 10 | kJ/m² | ISO 180/1A |
| Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm | 10 | kJ/m² | ISO 179/1eA |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/50 | 234 | °C | ASTM D 1525 |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 212 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, xflow | 4.5E-05 | 1/°C | ASTM E 831 |
| CTE, -20°C to 150°C, flow | 1.44E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, flow | 1.5E-05 | 1/°C | ISO 11359-2 |
| CTE, -40°C to 40°C, xflow | 4.5E-05 | 1/°C | ISO 11359-2 |
| Vicat Softening Temp, Rate B/50 | 214 | °C | ISO 306 |
| Vicat Softening Temp, Rate B/120 | 215 | °C | ISO 306 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 197 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.61 | - | ASTM D 792 |
| Water Absorption, 24 hours | 0.13 | % | ASTM D 570 |
| Water Absorption, equilibrium, 23C | 0.9 | % | ASTM D 570 |
| Mold Shrinkage, flow, 3.2 mm | 0.1 - 0.3 | % | S-Plastics Method |
| Melt Flow Rate, 337°C/6.6 kgf | 5.2 | g/10 min | ASTM D 1238 |
| Density | 1.56 | g/cm³ | ISO 1183 |
| Water Absorption, (23°C/sat) | 0.8 | % | ISO 62 |
| Moisture Absorption (23°C / 50% RH) | 0.4 | % | ISO 62 |
| Melt Volume Rate, MVR at 220°C/5.0 kg | 11 | cm³/10 min | ISO 1133 |
| ELECTRICAL | Value | Unit | Standard |
| Volume Resistivity | 1.5E+16 | Ohm-cm | ASTM D 257 |
| Dielectric Strength, in oil, 1.6 mm | 24 | kV/mm | ASTM D 149 |
| Relative Permittivity, 1 kHz | 3.7 | - | ASTM D 150 |
| Dissipation Factor, 1 kHz | 0.002 | - | ASTM D 150 |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| Oxygen Index (LOI) | 54 | % | ASTM D 2863 |
| Source GMD, last updated:05/23/2007 | |||
| Injection Molding | Value | Unit |
| Drying Temperature | 150 | °C |
| Drying Time | 4 - 6 | hrs |
| Drying Time (Cumulative) | 24 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 350 - 400 | °C |
| Nozzle Temperature | 345 - 400 | °C |
| Front - Zone 3 Temperature | 345 - 400 | °C |
| Middle - Zone 2 Temperature | 340 - 400 | °C |
| Rear - Zone 1 Temperature | 330 - 400 | °C |
| Mold Temperature | 135 - 165 | °C |
| Back Pressure | 0.3 - 0.7 | MPa |
| Screw Speed | 40 - 70 | rpm |
| Shot to Cylinder Size | 40 - 60 | % |
| Vent Depth | 0.025 - 0.076 | mm |
| Source GMD, last updated:05/23/2007 | ||
|
For more information please download the datasheet |
|
 |
S-Plastics Ultem HU2410.pdf |
|
