S-Plastics Ultem HU2400 resin is 40% Glass fiber filled, standard flow Polyimide (Tg 217C). For medical devices and pharmaceutical applications. Healthcare management of change, biocompatible (ISO 10993 or USP Class VI), food contact compliant.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 179 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 179 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 2.5 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 2.5 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 11720 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 241 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 11720 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 180 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 180 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 2 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 2 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 11500 | MPa | ISO 527 |
| Flexural Stress, break, 2 mm/min | 240 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 10000 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 112 | J/m | ASTM D 256 |
| Izod Impact, notched, -30°C | - | J/m | ASTM D 256 |
| Instrumented Impact Total Energy, 23°C | 28 | J | ASTM D 3763 |
| Izod Impact, unnotched 80*10*4 +23°C | 35 | kJ/m² | ISO 180/1U |
| Izod Impact, unnotched 80*10*4 -30°C | 35 | kJ/m² | ISO 180/1U |
| Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm | 40 | kJ/m² | ISO 179/1eU |
| Charpy -30°C, Unnotch Edgew 80*10*4 sp=62mm | 40 | kJ/m² | ISO 179/1eU |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/50 | 234 | °C | ASTM D 1525 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 212 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 1.44E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 1.44E-05 | 1/°C | ASTM E 831 |
| CTE, 23°C to 150°C, flow | 1.5E-05 | 1/°C | ISO 11359-2 |
| CTE, 23°C to 150°C, xflow | 4.5E-05 | 1/°C | ISO 11359-2 |
| Vicat Softening Temp, Rate B/50 | 217 | °C | ISO 306 |
| Vicat Softening Temp, Rate B/120 | 225 | °C | ISO 306 |
| HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm | 210 | °C | ISO 75/Ae |
| Relative Temp Index, Elec | 170 | °C | UL 746B |
| Relative Temp Index, Mech w/impact | 170 | °C | UL 746B |
| Relative Temp Index, Mech w/o impact | 170 | °C | UL 746B |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.61 | - | ASTM D 792 |
| Mold Shrinkage, flow, 3.2 mm | 0.1 - 0.3 | % | S-Plastics Method |
| Melt Flow Rate, 200°C/3.8 kgf | 4.2 | g/10 min | ASTM D 1238 |
| Density | 1.61 | g/cm³ | ISO 1183 |
| Water Absorption, (23°C/sat) | 0.8 | % | ISO 62 |
| Moisture Absorption (23°C / 50% RH) | 0.4 | % | ISO 62 |
| Melt Volume Rate, MVR at 360°C/5.0 kg | 5 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:05/04/2007 | |||
| Injection Molding | Value | Unit |
| Drying Temperature | 150 | °C |
| Drying Time | 4 - 6 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 370 - 410 | °C |
| Nozzle Temperature | 370 - 410 | °C |
| Front - Zone 3 Temperature | 380 - 420 | °C |
| Middle - Zone 2 Temperature | 370 - 410 | °C |
| Rear - Zone 1 Temperature | 350 - 390 | °C |
| Hopper Temperature | 80 - 100 | °C |
| Mold Temperature | 140 - 180 | °C |
| Source GMD, last updated:05/04/2007 | ||
|
