Custom S-Plastic Xenoy Resin XD1525 PCR PET Resin Pellets

100KG
MOQ
*USD
Price
Custom S-Plastic Xenoy Resin XD1525 PCR PET Resin Pellets
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Volume Rate, MVR At 265°C/1.2 Kg: 6
UL Compliant, 94HB Flame Class Rating (3)(4): 1.5
Highlight:

PCR Xenoy Resin

,

Xenoy Resin XD1525

,

Xenoy pcr pet resin

Basic Infomation
Place of Origin: ——
Brand Name: S-Plastic Xenoy
Certification: COA/ICP Test/Rohs/MSDS
Model Number: XD1525
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

S-Plastics Xenoy XD1525 resin is a high heat PC+PET blend, impact modified with an increased modulus. Material is developed for wheeltrim
applications.


Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Taber Abrasion, CS-17, 1 kg 20 mg/1000cy S-Plastics Method
Tensile Stress, yield, 50 mm/min 55 MPa ISO 527
Tensile Stress, break, 50 mm/min 58 MPa ISO 527
Tensile Strain, break, 50 mm/min 100 % ISO 527
Tensile Modulus, 1 mm/min 2300 MPa ISO 527
Flexural Stress, yield, 2 mm/min 85 MPa ISO 178
Flexural Modulus, 2 mm/min 2200 MPa ISO 178
Hardness, H358/30 95 MPa ISO 2039-1
IMPACT Value Unit Standard
Izod Impact, notched 80*10*4 +23°C 40 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 0°C 45 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 -20°C 20 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 -30°C 15 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm 45 kJ/m² ISO 179/1eA
Charpy -30°C, V-notch Edgew 80*10*4 sp=62mm 15 kJ/m² ISO 179/1eA
THERMAL Value Unit Standard
Thermal Conductivity 0.18 W/m-°C ISO 8302
CTE, 23°C to 80°C, flow 9.2E-05 1/°C ISO 11359-2
Ball Pressure Test, 125°C +/- 2°C PASSES - IEC 60695-10-2
Vicat Softening Temp, Rate A/50 145 °C ISO 306
TYPICAL PROPERTIES (2)     ISO 306
MECHANICAL Value Unit ISO 306
Taber Abrasion, CS-17, 2 kg 20 mg/1001cy ISO 75/Be
Tensile Stress, yield, 51 mm/min 55 MPa ISO 75/Ae
Tensile Stress, break, 51 mm/min 58 MPa Standard
Mold Shrinkage on Tensile Bar, flow (2) 0.5 - 0.8 % S-Plastics Method
Mold Shrinkage on Tensile Bar, xflow (2) 0.5 - 0.8 % S-Plastics Method
Density 1.21 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.7 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.2 % ISO 62
Melt Volume Rate, MVR at 265°C/1.2 kg 6 cm³/10 min ISO 1133
ELECTRICAL Value Unit Standard
Volume Resistivity >1.E+14 Ohm-cm IEC 60093
Surface Resistivity, ROA >1.E+15 Ohm IEC 60093
Dielectric Strength, in oil, 3.2 mm 17 kV/mm IEC 60243-1
Relative Permittivity, 50/60 Hz 3.3 - IEC 60250
Relative Permittivity, 1 MHz 3.1 - IEC 60250
Dissipation Factor, 50/60 Hz 0.002 - IEC 60250
Dissipation Factor, 1 MHz 0.02 - IEC 60250
FLAME CHARACTERISTICS Value Unit Standard
UL Compliant, 94HB Flame Class Rating (3)(4) 1.5 mm UL 94 by GE
Source GMD, last updated:12/14/1999

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 110 - 120 °C
Drying Time 4 - 6 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 265 - 275 °C
Nozzle Temperature 260 - 275 °C
Front - Zone 3 Temperature 260 - 280 °C
Middle - Zone 2 Temperature 250 - 275 °C
Rear - Zone 1 Temperature 240 - 270 °C
Hopper Temperature 60 - 80 °C
Mold Temperature 60 - 100 °C
Source GMD, last updated:12/14/1999
