S-Plastics Xenoy X6600EX resin isPolyester+PC. High Heat. Excellent chemcial resistance.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 50 mm/min | 54 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 50 mm/min | 27 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 50 mm/min | 3.9 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 50 mm/min | 43 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 2450 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 78 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 2440 | MPa | ASTM D 790 |
| Tensile Stress, yield, 50 mm/min | 57 | MPa | ISO 527 |
| Tensile Stress, break, 50 mm/min | 28 | MPa | ISO 527 |
| Tensile Strain, yield, 50 mm/min | 4.1 | % | ISO 527 |
| Tensile Strain, break, 50 mm/min | 27.7 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 2490 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 80 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 2300 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 59 | J/m | ASTM D 256 |
| Izod Impact, notched 80*10*4 +23°C | 5 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 85 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 77 | °C | ASTM D 648 |
| Vicat Softening Temp, Rate B/120 | 120 | °C | ISO 306 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 67 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.36 | - | ASTM D 792 |
| Melt Flow Rate, 266°C/5.0 kgf | 24.1 | g/10 min | ASTM D 1238 |
| Density | 1.36 | g/cm³ | ISO 1183 |
| Melt Volume Rate, MVR at 265°C/2.16 kg | 6 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:2007/06/15 | |||
| Parameter | ||
| Extrusion Blow Molding | Value | Unit |
| Drying Temperature | 100 - 105 | °C |
| Drying Time | 3 - 4 | hrs |
| Drying Time (Cumulative) | 12 | hrs |
| Maximum Moisture Content | 0.01 - 0.03 | % |
| Melt Temperature (Parison) | 255 - 265 | °C |
| Barrel - Zone 1 Temperature | 250 - 260 | °C |
| Barrel - Zone 2 Temperature | 250 - 260 | °C |
| Barrel - Zone 3 Temperature | 255 - 260 | °C |
| Barrel - Zone 4 Temperature | 255 - 265 | °C |
| Adapter - Zone 5 Temperature | 255 - 265 | °C |
| Head - Zone 6 - Top Temperature | 255 - 265 | °C |
| Head - Zone 7 - Middle Temperature | 255 - 265 | °C |
| Head - Zone 7 - Bottom Temperature | 255 - 265 | °C |
| Screw Speed | 15 - 50 | rpm |
| Extruder Feed Zone Temperature | 255 - 265 | °C |
| Accumulator Temperature | 255 - 265 | °C |
| Mold Temperature | 50 - 95 | °C |
| Die Temperature | 255 - 265 | °C |
| Source GMD, last updated:2007/06/15 | ||
