S-Plastics Cycoloy MC5300 resin is a high heat, flame retardant PC/ABS blend. MC5300 resin passes UL-94 listing of 1.5mm V0 and 2.5mm 5VB.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 62 | MPa | S-Plastics - Japan Method |
| Tensile Strain, break | 160 - 160 | % | S-Plastics - Japan Method |
| Flexural Stress | 93 | MPa | ASTM D 790 |
| Flexural Modulus | 2400 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 794 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 120 | °C | ASTM D 648 |
| CTE, -30°C to 30°C | 6.E-05 - 8.E-05 | 1/°C | TMA |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.19 | - | ASTM D 792 |
| Water Absorption, 24 hours | 0.2 | % | ASTM D 570 |
| Mold Shrinkage, flow, 3.2 mm | 0.4 - 0.6 | % | S-Plastics Method |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| UL Recognized, 94V-0 Flame Class Rating (3) | 1.5 | mm | UL 94 |
| UL Recognized, 94-5VB Rating (3) | 2.5 | mm | UL 94 |
| Source GMD, last updated:03/20/2007 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 100 | °C |
| Drying Time | 2 | hrs |
| Melt Temperature | 250 - 260 | °C |
| Nozzle Temperature | 250 - 260 | °C |
| Front - Zone 3 Temperature | 250 - 260 | °C |
| Middle - Zone 2 Temperature | 240 - 250 | °C |
| Rear - Zone 1 Temperature | 230 - 240 | °C |
| Back Pressure | 4.9 - 9.8 | MPa |
| Screw Speed | 50 - 100 | rpm |
| Source GMD, last updated:03/20/2007 | ||
|
