S-Plastic Xylex EXXX0088 Low Flow PC+Polyester Alloy For Film/Sheet Extrusion.

100KG
MOQ
*USD
Price
S-Plastic Xylex EXXX0088 Low Flow PC+Polyester Alloy For Film/Sheet Extrusion.
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Flow Rate, 265°C/2.16kg: 3
Alloy: PC+Polyester
Application: Film/Sheet Extrusion
Basic Infomation
Place of Origin: ——
Brand Name: S-Plastic Xylex
Certification: COA/ICP Test/Rohs/MSDS
Model Number: EXXX0088
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

S-Plastics Xylex EXXX0088 resin is Low flow PC+Polyester alloy for film/sheet extrusion.


Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 62 MPa ASTM D 638
Tensile Stress, brk, Type I, 50 mm/min 65 MPa ASTM D 638
Tensile Strain, yld, Type I, 50 mm/min 6 % ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 110 % ASTM D 638
Tensile Modulus, 50 mm/min 2300 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 95 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 2280 MPa ASTM D 790
Tensile Stress, yield, 50 mm/min 60 MPa ISO 527
Tensile Stress, break, 50 mm/min 65 MPa ISO 527
Tensile Strain, yield, 50 mm/min 6 % ISO 527
Tensile Strain, break, 50 mm/min 135 % ISO 527
Tensile Modulus, 1 mm/min 2400 MPa ISO 527
Flexural Stress, yield, 2 mm/min 93 MPa ISO 178
Flexural Modulus, 2 mm/min 2180 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 1000 J/m ASTM D 256
Izod Impact, notched, -30°C 80 J/m ASTM D 256
Instrumented Impact Total Energy, 23°C 85 J ASTM D 3763
Izod Impact, notched 80*10*4 +23°C 15 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 -30°C 6 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm 22 kJ/m² ISO 179/1eA
THERMAL Value Unit Standard
Vicat Softening Temp, Rate B/50 130 °C ASTM D 1525
HDT, 0.45 MPa, 3.2 mm, unannealed 122 °C ASTM D 648
HDT, 1.82 MPa, 3.2mm, unannealed 111 °C ASTM D 648
CTE, -40°C to 95°C, flow 7.E-05 1/°C ASTM E 831
CTE, -40°C to 95°C, xflow 7.E-05 1/°C ASTM E 831
CTE, -40°C to 40°C, flow 7.E-05 1/°C ISO 11359-2
CTE, -40°C to 40°C, xflow 7.E-05 1/°C ISO 11359-2
Vicat Softening Temp, Rate B/50 127 °C ISO 306
Vicat Softening Temp, Rate B/120 129 °C ISO 306
HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm 111 °C ISO 75/Ae
PHYSICAL Value Unit Standard
Specific Gravity 1.2 - ASTM D 792
Mold Shrinkage, flow, 3.2 mm 0.6 - 0.8 % S-Plastics Method
Melt Flow Rate, 265°C/2.16kg 3 g/10 min ASTM D 1238
Density 1.2 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.28 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.07 % ISO 62
Melt Volume Rate, MVR at 265°C/2.16 kg 3 cm³/10 min ISO 1133
Source GMD, last updated:10/30/2006

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 70 - 90 °C
Drying Time 3 - 5 hrs
Drying Time (Cumulative) 8 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 270 - 300 °C
Nozzle Temperature 265 - 295 °C
Front - Zone 3 Temperature 270 - 300 °C
Middle - Zone 2 Temperature 260 - 290 °C
Rear - Zone 1 Temperature 250 - 270 °C
Mold Temperature 45 - 80 °C
Back Pressure 0.2 - 0.5 MPa
Screw Speed 20 - 100 rpm
Shot to Cylinder Size 40 - 80 %
Vent Depth 0.013 - 0.02 mm
Parameter
Film Extrusion Value Unit
Drying Temperature 85 - 95 °C
Drying Time 4 hrs
Drying Time (Cumulative) 8 hrs
Maximum Moisture Content 0.02 %
Barrell Temperature - Rear 250 - 290 °C
Barrell Temperature - Middle 250 - 290 °C
Barrell Temperature - Front 250 - 290 °C
Die Temperature 250 - 290 °C
Roll Temperature 75 - 125 °C
Melt Pump Speed 15 - 50 rpm
Source GMD, last updated:10/30/2006
