S-Plastics Verton N3000 resin is Antistatic PC + ABS Blend compound. Added features include FDA compliant Raw Materials.
| Property | |||
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Strain, yield, 5 mm/min | 5.4 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 123 | % | ISO 527 |
| Flexural Modulus, 2 mm/min | 1700 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched 80*10*4 +23°C | 100 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 46 | kJ/m² | ISO 180/1A |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.14 | g/cm³ | ISO 1183 |
| ELECTRICAL | Value | Unit | Standard |
| Surface Resistivity, ROA | 1.E+09 - 1.E+11 | Ohm | IEC 60093 |
| Source GMD, last updated:11/01/2007 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 80 | °C |
| Drying Time | 4 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 220 - 260 | °C |
| Front - Zone 3 Temperature | 245 - 255 | °C |
| Middle - Zone 2 Temperature | 230 - 245 | °C |
| Rear - Zone 1 Temperature | 220 - 230 | °C |
| Mold Temperature | 40 - 80 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:11/01/2007 | ||
