S-Plastics Geloy 29453A resin is a medium heat weatherable ASA+PC resin. The grade is only available in VisualFx.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield, 50 mm/min | 55 | MPa | ISO 527 |
| Tensile Stress, break, 50 mm/min | 45 | MPa | ISO 527 |
| Tensile Strain, yield, 50 mm/min | 4.3 | % | ISO 527 |
| Tensile Strain, break, 50 mm/min | 16 | % | ISO 527 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched 80*10*4 +23°C | 10 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/120 | 112 | °C | ISO 306 |
| HDT/Be, 0.45MPa Edgew 120*10*4 sp=100mm | 110 | °C | ISO 75/Be |
| HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm | 90 | °C | ISO 75/Ae |
| PHYSICAL | Value | Unit | Standard |
| Melt Volume Rate, MVR at 260°C/5.0 kg | 22 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:02/20/2003 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 90 - 105 | °C |
| Drying Time | 2 - 6 | hrs |
| Maximum Moisture Content | 0.04 | % |
| Melt Temperature | 260 - 275 | °C |
| Mold Temperature | 50 - 70 | °C |
| Source GMD, last updated:02/20/2003 | ||
Other related products we recommend:
|
For more information please download the datasheet |
|
 |
S-Plastics Geloy 29453A.pdf |
|
