S-Plastics Faradex MS003 resin is a compound based on Polypropylene resin containing Stainless Steel. Added features of this material include:Electrically Conductive, EMI/RFI Shielding
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 19 | MPa | ASTM D 638 |
| Tensile Stress, break | 15 | MPa | ASTM D 638 |
| Tensile Strain, yield | 6.2 | % | ASTM D 638 |
| Tensile Strain, break | 88.4 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 1190 | MPa | ASTM D 638 |
| Flexural Stress | 27 | MPa | ASTM D 790 |
| Flexural Modulus | 1190 | MPa | ASTM D 790 |
| Tensile Stress, yield | 21 | MPa | ISO 527 |
| Tensile Stress, break | 15 | MPa | ISO 527 |
| Tensile Strain, yield | 5.2 | % | ISO 527 |
| Tensile Strain, break | 72 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 1300000 | MPa | ISO 527 |
| Flexural Stress | 32 | MPa | ISO 178 |
| Flexural Modulus | 1500 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 1226 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 267 | J/m | ASTM D 256 |
| Multiaxial Impact | 22 | J | ISO 6603 |
| Izod Impact, unnotched 80*10*4 +23°C | 80 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 25 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 92 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 53 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 1.04E-04 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 9.72E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, flow | 1.43E-04 | 1/°C | ISO 11359-2 |
| CTE, -40°C to 40°C, xflow | 1.7E-04 | 1/°C | ISO 11359-2 |
| HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 95 | °C | ISO 75/Bf |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 56 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.01 | g/cm³ | ASTM D 792 |
| Source GMD, last updated:02/27/2007 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 80 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 230 - 250 | °C |
| Front - Zone 3 Temperature | 260 - 270 | °C |
| Middle - Zone 2 Temperature | 230 - 245 | °C |
| Rear - Zone 1 Temperature | 205 - 215 | °C |
| Mold Temperature | 30 - 55 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 25 - 50 | rpm |
| Source GMD, last updated:02/27/2007 | ||
