WFL34 WFL-4034 S-Plastic Lubricomp Polybutylene Terephalate Resin

100KG
MOQ
*USD
Price
WFL34 WFL-4034 S-Plastic Lubricomp Polybutylene Terephalate Resin
Features Gallery Product Description Request A Quote
Features
Specifications
Density: 1.57
Mold Shrinkage, Flow: 0.4
Highlight:

Polybutylene Terephalate S-Plastic Lubricomp

,

Polybutylene S-Plastic Lubricomp

,

S-Plastic polybutylene resin

Basic Infomation
Place of Origin: ——
Brand Name: S-Plastic Lubricomp
Certification: COA/ICP Test/Rohs/MSDS
Model Number: WFL34
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

S-Plastics Lubricomp WFL34 resin is

"Also known as: WFL-4034
Product Reorder Name: WFL34"
"LNP LUBRICOMP* WFL34 is a compound based on Polybutylene Terephalate resin containing Glass Fiber, PTFE. Added features of this
material include: Internally Lubricated."




Property


TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, break 113 MPa ASTM D 638
Tensile Strain, break 2.7 % ASTM D 638
Tensile Modulus, 50 mm/min 7990 MPa ASTM D 638
Flexural Stress 166 MPa ASTM D 790
Flexural Modulus 7030 MPa ASTM D 790
Tensile Stress, break 112 MPa ISO 527
Tensile Strain, break 2.5 % ISO 527
Tensile Modulus, 1 mm/min 7800 MPa ISO 527
Flexural Stress 173 MPa ISO 178
Flexural Modulus 7700 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, unnotched, 23°C 683 J/m ASTM D 4812
Izod Impact, notched, 23°C 80 J/m ASTM D 256
Instrumented Impact Energy @ peak, 23°C 8 J ASTM D 3763
Izod Impact, unnotched 80*10*4 +23°C 43 kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 9 kJ/m² ISO 180/1A
THERMAL Value Unit Standard
HDT, 0.45 MPa, 3.2 mm, unannealed 224 °C ASTM D 648
HDT, 1.82 MPa, 3.2mm, unannealed 212 °C ASTM D 648
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 210 °C ISO 75/Af
PHYSICAL Value Unit Standard
Density 1.57 g/cm³ ASTM D 792
Moisture Absorption, 50% RH, 24 hrs 0.03 % ASTM D 570
Mold Shrinkage, flow, 24 hrs 0.4 % ASTM D 955
Mold Shrinkage, xflow, 24 hrs 1.1 % ASTM D 955
Mold Shrinkage, flow, 24 hrs 0.39 % ISO 294
Mold Shrinkage, xflow, 24 hrs 1.11 % ISO 294
Wear Factor Washer 34 10^-10 in^5-min/ft-lb-hr ASTM D 3702 Modified
Dynamic COF 0.29 - ASTM D 3702 Modified
Static COF 0.2 - ASTM D 3702 Modified
Density 1.57 g/cm³ ISO 1183
Moisture Absorption (23°C / 50% RH) 0.18 % ISO 62
Source GMD, last updated:09/30/2004



Processing



Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 4 hrs
Maximum Moisture Content 0.05 %
Melt Temperature 240 - 265 °C
Front - Zone 3 Temperature 260 - 270 °C
Middle - Zone 2 Temperature 245 - 255 °C
Rear - Zone 1 Temperature 220 - 230 °C
Mold Temperature 80 - 100 °C
Back Pressure 0.2 - 0.3 MPa
Screw Speed 30 - 60 rpm
Source GMD, last updated:09/30/2004



Our customers

In recent years, we have deeply cultivated the domestic market and actively explored foreign markets.Up to now, we have provided high-quality products and services to more than 1,000 customers in various industries, including: electronics and electrical appliances, medical, food, automotive electronics, optoelectronic communications, photovoltaic new energy, water treatment, transportation and other industries.


Samtion chemical supplies engineering plastics and special modified materials of S-Plastics and other brands.Our authentic products are guaranteed, with complete qualifications and superior supply capacity and price advantages.
Every batch of our products is subject to strict quality inspection to ensure the original supply. All products have MSDS, ROHS, SGS, REACH, FDA, EU, UL, COC / COA certificates!!





For more information please download the datesheet

WFL34 WFL-4034 S-Plastic Lubricomp Polybutylene Terephalate Resin 0  S-Plastics Lubricomp WFL34.pdf
