Modified Polyphenylene Oxide PPO Resin White Plastic Pellets S-Plastic Lubricomp ZFL24 ZFL-4024

100KG
MOQ
*USD
Price
Modified Polyphenylene Oxide PPO Resin White Plastic Pellets S-Plastic Lubricomp ZFL24 ZFL-4024
Features Gallery Product Description Request A Quote
Features
Specifications
Density: 1.29
Mold Shrinkage, Flow: 0.3 - 0.6
Highlight:

Polyphenylene Oxide ppo resin

,

Lubricomp ppo resin

,

Lubricomp white plastic pellets

Basic Infomation
Place of Origin: ——
Brand Name: S-Plastic Lubricomp
Certification: COA/ICP Test/Rohs/MSDS
Model Number: ZFL24
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

 S-Plastics Lubricomp ZFL24 resin is

"Also known as: LUBRICOMP ZFL-4024
Product Reorder Name: ZFL24"
LNP* Lubricomp* ZFL24 is a compound based on Modified Polyphenylene Oxide (PPO) containing glass fiber and PTFE lubricant.
Characteristics of this grade are: Internally Lubricated.




Property


TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, brk, Type I, 5 mm/min 96 MPa ASTM D 638
Tensile Strain, brk, Type I, 5 mm/min 2 % ASTM D 638
Tensile Modulus, 50 mm/min 7540 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 144 MPa ASTM D 790
Flexural Stress, brk, 1.3 mm/min, 50 mm span 143 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 6880 MPa ASTM D 790
Tensile Stress, break, 5 mm/min 92 MPa ISO 527
Tensile Strain, break, 5 mm/min 1.9 % ISO 527
Tensile Modulus, 1 mm/min 7120 MPa ISO 527
Flexural Stress 138 MPa ISO 178
Flexural Modulus, 2 mm/min 6570 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, unnotched, 23°C 469 J/m ASTM D 4812
Izod Impact, notched, 23°C 99 J/m ASTM D 256
Multiaxial Impact 3 J ISO 6603
Instrumented Impact Total Energy, 23°C 10 J ASTM D 3763
Izod Impact, unnotched 80*10*4 +23°C 28 kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 9 kJ/m² ISO 180/1A
THERMAL Value Unit Standard
HDT, 0.45 MPa, 3.2 mm, unannealed 136 °C ASTM D 648
HDT, 1.82 MPa, 3.2mm, unannealed 131 °C ASTM D 648
CTE, -30°C to 30°C, flow 7.2E+01 1/°C ASTM D 696
CTE, -30°C to 30°C, xflow 5.6E+01 1/°C ASTM D 696
HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm 136 °C ISO 75/Bf
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 130 °C ISO 75/Af
PHYSICAL Value Unit Standard
Specific Gravity 1.29 - ASTM D 792
Density 1.29 g/cm³ ASTM D 792
Moisture Absorption, 50% RH, 24 hrs 0.06 % ASTM D 570
Mold Shrinkage, flow, 24 hrs (5) 0.3 - 0.6 % ASTM D 955
Mold Shrinkage, xflow, 24 hrs (5) 0.5 - 0.8 % ASTM D 955
Wear Factor Washer 101 10^-10 in^5-min/ft-lb-hr ASTM D 3702 Modified
Wear Factor Ring 19 10^-10 in^5-min/ft-lb-hr ASTM D 3702 Modified
Dynamic COF 0.47 - ASTM D 3702 Modified
Static COF 0.54 - ASTM D 3702 Modified
Moisture Absorption (23°C / 50% RH) 0.14 % ISO 62
Source GMD, last updated:2009/07/28



Processing



Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 4 hrs
Melt Temperature 300 - 305 °C
Front - Zone 3 Temperature 300 - 310 °C
Middle - Zone 2 Temperature 290 - 300 °C
Rear - Zone 1 Temperature 275 - 290 °C
Mold Temperature 80 - 110 °C
Back Pressure 0.2 - 0.3 MPa
Screw Speed 30 - 60 rpm
Source GMD, last updated:2009/07/28




Our customers

In recent years, we have deeply cultivated the domestic market and actively explored foreign markets.Up to now, we have provided high-quality products and services to more than 1,000 customers in various industries, including: electronics and electrical appliances, medical, food, automotive electronics, optoelectronic communications, photovoltaic new energy, water treatment, transportation and other industries.


Samtion chemical supplies engineering plastics and special modified materials of S-Plastics and other brands.Our authentic products are guaranteed, with complete qualifications and superior supply capacity and price advantages.
Every batch of our products is subject to strict quality inspection to ensure the original supply. All products have MSDS, ROHS, SGS, REACH, FDA, EU, UL, COC / COA certificates!!





For more information please download the datesheet

Modified Polyphenylene Oxide PPO Resin White Plastic Pellets S-Plastic Lubricomp ZFL24 ZFL-4024 0  S-Plastics Lubricomp ZFL24.pdf
