S-Plastics Valox EXVX0025resin is 50% Glass Fiber Reinforced PBT-PET resin
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield, 5 mm/min | 175 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 175 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 1.5 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 1.5 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 17500 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 255 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 16000 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched 80*10*4 +23°C | 40 | kJ/m² | ISO 180/1U |
| Izod Impact, unnotched 80*10*4 -30°C | 40 | kJ/m² | ISO 180/1U |
| THERMAL | Value | Unit | Standard |
| CTE, 23°C to 80°C, flow | 1.5E-05 | 1/°C | ISO 11359-2 |
| CTE, 23°C to 80°C, xflow | 7.2E-05 | 1/°C | ISO 11359-2 |
| Vicat Softening Temp, Rate B/120 | 210 | °C | ISO 306 |
| HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm | 206 | °C | ISO 75/Ae |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.76 | g/cm³ | ISO 1183 |
| Melt Volume Rate, MVR at 265°C/2.16 kg | 7 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:09/04/2007 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 105 | °C |
| Drying Time | 3 - 4 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 270 - 300 | °C |
| Mold Temperature | 65 - 95 | °C |
| Source GMD, last updated:09/04/2007 | ||
Other related products we recommend:
|
For more information please download the datasheet |
|
 |
S-Plastics Valox EXVX0025.pdf |
|
