S-Plastics Valox 404 resin
| MECHANICAL | Value | Unit |
| Tensile Stress, yield | 101 | MPa |
| Tensile Strain, break | 3 - 3 | % |
| Flexural Stress | 148 | MPa |
| Flexural Modulus | 6520 | MPa |
| Hardness, Rockwell R | 97 | - |
| IMPACT | Value | Unit |
| Izod Impact, notched, 23°C | 177 | J/m |
| THERMAL | Value | Unit |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 205 | °C |
| CTE, -30°C to 30°C | 3.E-05 - 3.E-05 | 1/°C |
| PHYSICAL | Value | Unit |
| Specific Gravity | 1.48 | - |
| Water Absorption, 24 hours | 0.06 | % |
| Mold Shrinkage, flow, 3.2 mm | 0.2 - 0.3 | % |
| Mold Shrinkage, flow, 6.4 mm | 0.6 - 0.8 | % |
| ELECTRICAL | Value | Unit |
| Surface Resistivity | 1.E+16 | Ohm |
| Arc Resistance, Tungsten {PLC} | 5 | PLC Code |
| FLAME CHARACTERISTICS | Value | Unit |
| UL Recognized, 94HB Flame Class Rating (3) | 1.5 | mm |
| Source GMD, last updated:02/03/2000 | ||
|
For more information please download the datasheet |
|
 |
S-Plastics Valox 404.pdf |
|
