S-Plastics Verton PV007SV_WH8D537 resin is Preliminary data for 35% long fiber single pellet color filled PA6
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, brk, Type I, 5 mm/min | 175 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 2.6 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 9160 | MPa | ASTM D 638 |
| Flexural Stress, yield, 2 mm/min | 261 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 7990 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 1270 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 188 | J/m | ASTM D 256 |
| Izod Impact, notched, -40°C | 233 | J/m | ASTM D 256 |
| Izod Impact, unnotched 80*10*4 +23°C | 82 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 19 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -40°C | 27 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 215 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.39 | g/cm³ | ASTM D 792 |
| Source GMD, last updated:08/12/2008 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 80 | °C |
| Drying Time | 4 | hrs |
| Maximum Moisture Content | 0.15 - 0.25 | % |
| Melt Temperature | 270 - 295 | °C |
| Front - Zone 3 Temperature | 270 - 290 | °C |
| Middle - Zone 2 Temperature | 270 - 290 | °C |
| Rear - Zone 1 Temperature | 260 - 275 | °C |
| Mold Temperature | 85 - 100 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 20 - 60 | rpm |
| Source GMD, last updated:08/12/2008 | ||
