S-Plastics Verton MV00ASUV_WH9D703 resin is Preliminary data for 50% Long fiber single color pellet filled PP
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 136 | MPa | ISO 527 |
| Tensile Stress, break | 136 | MPa | ISO 527 |
| Tensile Strain, yield | 1.9 | % | ISO 527 |
| Tensile Strain, break | 1.9 | % | ISO 527 |
| Flexural Modulus, 2 mm/min | 9430 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Instrumented Impact Energy @ peak, 23°C | 7 | J | ASTM D 3763 |
| Instrumented Impact Total Energy, 23°C | 11 | J | ASTM D 3763 |
| Izod Impact, unnotched 80*10*4 +23°C | 53 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 22 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -40°C | 22 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 153 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.35 | g/cm³ | ASTM D 792 |
| Source GMD, last updated:09/09/2008 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 80 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 220 - 250 | °C |
| Front - Zone 3 Temperature | 250 - 260 | °C |
| Middle - Zone 2 Temperature | 245 - 255 | °C |
| Rear - Zone 1 Temperature | 230 - 245 | °C |
| Mold Temperature | 40 - 65 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:09/09/2008 | ||
