S-Plastics Thermocomp EXCP0156 resin is a 50% carbon filled polyamide 6 resin with improved thermal conductivity.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, break, 5 mm/min | 44 | MPa | ISO 527 |
| Tensile Strain, break, 5 mm/min | 1 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 7300 | MPa | ISO 527 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched 80*10*4 +23°C | 10 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 4 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/120 | 196 | °C | ISO 306 |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.43 | g/cm³ | ISO 1183 |
| ELECTRICAL | Value | Unit | Standard |
| Surface Resistivity, ROA | 9.E+05 | Ohm | IEC 60093 |
| Source GMD, last updated:02/11/2003 | |||
