S-Plastics Thermocomp 9X07435X resin is ……………………
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 60 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 59 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 1.8 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 1.9 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 5450 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 95 | MPa | ASTM D 790 |
| Flexural Stress, brk, 1.3 mm/min, 50 mm span | 95 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 5350 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 51 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 51 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 1.5 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 1.5 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 4810 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 93 | MPa | ISO 178 |
| Flexural Strain, break, 2 mm/min | 2.2 | % | ISO 178 |
| Flexural Modulus, 2 mm/min | 5010 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 272 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 35 | J/m | ASTM D 256 |
| Izod Impact, unnotched 80*10*4 +23°C | 18 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 3 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 101 | °C | ASTM D 648 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 110 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.25 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.09 | % | ASTM D 570 |
| Mold Shrinkage, flow, 24 hrs | 0.9 - 1.1 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 1.1 - 1.3 | % | ASTM D 955 |
| ELECTRICAL | Value | Unit | Standard |
| Relative Permittivity, 1 GHz | 2.9 | - | ASTM D 150 |
| Dissipation Factor, 1 GHz | 0.0046 | - | ASTM D 150 |
| Source GMD, last updated:02/07/2008 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 95 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 300 - 310 | °C |
| Nozzle Temperature | 300 - 310 | °C |
| Front - Zone 3 Temperature | 300 - 310 | °C |
| Middle - Zone 2 Temperature | 300 - 310 | °C |
| Rear - Zone 1 Temperature | 300 - 310 | °C |
| Mold Temperature | 105 - 120 | °C |
| Back Pressure | 50 - 100 | MPa |
| Source GMD, last updated:02/07/2008 | ||
