S-Plastics Thermocomp UX05504 resin is a compound based on Polyphthalamide resin containing Glass Fiber. Added features of this materialinclude: Heat Stabilized.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 12 | MPa | ISO 527 |
| Tensile Stress, break | 164 | MPa | ISO 527 |
| Tensile Strain, break | 2 | % | ISO 527 |
| Flexural Stress | 295 | MPa | ISO 178 |
| Flexural Modulus | 10000 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched 80*10*4 +23°C | 39 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 7 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 260 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.44 | g/cm³ | ISO 1183 |
| Source GMD, last updated:06/27/2005 | |||
Other related products we recommend:
|
For more information please download the datasheet |
|
 |
S-Plastics Thermocomp UX05504.pdf |
|
