S-Plastics Thermocomp UFW49S resin is a compound based on Polyphthalamide resin containing Glass Fiber, Mineral. Added features of thismaterial include: Heat Stabilized, Low Warpage.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, break | 192 | MPa | ISO 527 |
| Tensile Strain, break | 1.1 | % | ISO 527 |
| Flexural Stress | 274 | MPa | ISO 178 |
| Flexural Modulus | 19300 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched 80*10*4 +23°C | 37 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 6 | kJ/m² | ISO 180/1A |
| PHYSICAL | Value | Unit | Standard |
| Mold Shrinkage, flow, 24 hrs | 0.25 | % | ISO 294 |
| Density | 1.87 | g/cm³ | ISO 1183 |
| Source GMD, last updated:10/02/2004 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 120 - 150 | °C |
| Drying Time | 4 | hrs |
| Maximum Moisture Content | 0.15 - 0.15 | % |
| Melt Temperature | 315 - 330 | °C |
| Front - Zone 3 Temperature | 325 - 340 | °C |
| Middle - Zone 2 Temperature | 315 - 325 | °C |
| Rear - Zone 1 Temperature | 310 - 320 | °C |
| Mold Temperature | 140 - 165 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:10/02/2004 | ||
