S-Plastics Thermocomp NX07354 resin is a PC/ABS compound, a good candidate for Laser Direct Structuring applications.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 50 mm/min | 53 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 43 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 50 mm/min | 42.3 | % | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 4.7 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 2340 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 82 | MPa | ASTM D 790 |
| Flexural Stress, brk, 1.3 mm/min, 50 mm span | 80 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 2310 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 53 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 42 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 4.6 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 40 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 2300 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 83 | MPa | ISO 178 |
| Flexural Strain, break, 2 mm/min | 7.4 | % | ISO 178 |
| Flexural Modulus, 2 mm/min | 2240 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 606 | J/m | ASTM D 256 |
| Izod Impact, notched 80*10*4 +23°C | 54 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 106 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 7.55E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 8.48E-05 | 1/°C | ASTM E 831 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 105 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.23 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.2 | % | ASTM D 570 |
| Mold Shrinkage, flow | 0.74 | % | S-Plastics Method |
| Mold Shrinkage, xflow | 0.63 | % | S-Plastics Method |
| Density | 1.23 | g/cm³ | ISO 1183 |
| ELECTRICAL | Value | Unit | Standard |
| Relative Permittivity, 1 GHz | 2.74 | - | ASTM D 150 |
| Dissipation Factor, 1 GHz | 0.003 | - | ASTM D 150 |
| Source GMD, last updated:2009/02/05 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 85 - 100 | °C |
| Drying Time | 6 - 8 | hrs |
| Melt Temperature | 240 - 280 | °C |
| Nozzle Temperature | 240 - 280 | °C |
| Front - Zone 3 Temperature | 240 - 270 | °C |
| Middle - Zone 2 Temperature | 240 - 260 | °C |
| Rear - Zone 1 Temperature | 240 - 260 | °C |
| Mold Temperature | 60 - 100 | °C |
| Back Pressure | 0.3 - 0.7 | MPa |
| Screw Speed | 40 - 70 | rpm |
| Source GMD, last updated:2009/02/05 | ||
