S-Plastics NoryL EXNL0303 resin is EXNL0303 is a modified PPE-HIPS blend that presents an excellent balance of non halogenated flame retardance, lower smoke
production upon burning and low specific gravity for light weight parts. Noryl EXNL0303 is available in custom colors and may be an
excellent material candidate for applications requiring light weight parts and may be processed by injection molding or extrusion
techniques.
Property
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 50 mm/min | 56 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 50 mm/min | 47 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 50 mm/min | 4.1 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 50 mm/min | 17 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 2280 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 90 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 2360 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 156 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 104 | °C | ASTM D 648 |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.05 | - | ASTM D 792 |
| Melt Flow Rate, 280°C/5.0 kgf | 27 | g/10 min | ASTM D 1238 |
| Source GMD, last updated:11/21/2007 | |||
| Parameter | |||
| Injection Molding | Value | Unit | |
| Drying Temperature | 95 - 105 | °C | |
| Drying Time | 2 - 4 | hrs | |
| Drying Time (Cumulative) | 12 | hrs | |
| Maximum Moisture Content | 0.07 | % | |
| Melt Temperature | 260 - 290 | °C | |
| Nozzle Temperature | 260 - 290 | °C | |
| Front - Zone 3 Temperature | 250 - 290 | °C | |
| Middle - Zone 2 Temperature | 240 - 280 | °C | |
| Rear - Zone 1 Temperature | 225 - 275 | °C | |
| Mold Temperature | 65 - 100 | °C | |
| Back Pressure | 0.3 - 0.7 | MPa | |
| Screw Speed | 20 - 100 | rpm | |
| Shot to Cylinder Size | 30 - 70 | % | |
| Vent Depth | 0.038 - 0.051 | mm | |
| Parameter | |||
| Sheet Extrusion | Value | Unit | |
| Drying Temperature | 95 - 105 | °C | |
| Drying Time | 2 - 4 | hrs | |
| Drying Time (Cumulative) | 12 | hrs | |
| Maximum Moisture Content | 0.07 | % | |
| Melt Temperature | 215 - 250 | °C | |
| Barrel - Zone 1 Temperature | 215 - 250 | °C | |
| Barrel - Zone 2 Temperature | 215 - 250 | °C | |
| Barrel - Zone 3 Temperature | 215 - 250 | °C | |
| Barrel - Zone 4 Temperature | 215 - 250 | °C | |
| Adapter Temperature | 215 - 250 | °C | |
| Die Temperature | 215 - 250 | °C | |
| Roll Stack Temp - Top | 90 - 150 | °C | |
| Roll Stack Temp - Middle | 90 - 150 | °C | |
| Roll Stack Temp - Bottom | 90 - 150 | °C | |
| Parameter | |||
| Profile Extrusion | Value | Unit | |
| Drying Temperature | 95 - 105 | °C | |
| Drying Time | 2 - 4 | hrs | |
| Drying Time (Cumulative) | 12 | hrs | |
| Maximum Moisture Content | 0.07 | % | |
| Melt Temperature | 215 - 250 | °C | |
| Barrel - Zone 1 Temperature | 215 - 250 | °C | |
| Barrel - Zone 2 Temperature | 215 - 250 | °C | |
| Barrel - Zone 3 Temperature | 215 - 250 | °C | |
| Barrel - Zone 4 Temperature | 215 - 250 | °C | |
| Hopper Temperature | 80 - 120 | °C | |
| Adapter Temperature | 215 - 250 | °C | |
| Die Temperature | 215 - 250 | °C | |
| Calibrator Temperature | 30 - 60 | °C | |
| Water Bath Temperature | 30 - 50 | °C | |
| Source GMD, last updated:11/21/2007 | |||
Other related products we recommend:
Drinking water / food grade:731,731S,GFN10F,GFN20F,GFN30F,GFN1520V,GFN1630V(Color requirements)
Unreinforce and flame retardant: 0150B,N190X,PX9406P,SE100X
Reinforce and flame retardant: SE1GFN1,SE1GFN2,SE1GFN3,HS2000X
|
For more information please see below |
|
 |
S-Plastics Noryl EXNL0303.pdf |
|
Get The Latest Quotation 5000 kinds of products 1000 tons of spot inventory First-level distribution source in South China Reduce procurement costs, improve supply stability, Help you find the most suitable engineering plastic materials
|
|
S-Plastics Noryl Resin Application
|
S-Plastics Noryl PPO is modified polyphenylene oxide (PPO) resins produced by the S-Plastics company. It is known for its excellent balance of properties, including high heat resistance, dimensional stability, and chemical resistance.
Noryl PPO resins are produced by blending PPO with other materials, such as polystyrene or polyamide.S-Plastics Noryl PPO include: |
|
|
| 3. Chemical resistance: S-Plastics Noryl PPO has good chemical resistance. It is commonly used in automotive and electrical applications where chemical resistance is important. 4. Good electrical properties: S-Plastics Noryl PPO has good electrical properties. This makes it suitable for use in electrical and electronic applications, such as connectors and switches. 5. Ease of processing: S-Plastics Noryl PPO is easy to process and can be easily molded into complex shapes with thin walls. |
||
