Sabic Noryl EXNL0141 Is An Unfilled Modified Polyphenylene Ether Resin Suitable For Injection Molding

100KG
MOQ
*USD
Price
Sabic Noryl EXNL0141 Is An Unfilled Modified Polyphenylene Ether Resin Suitable For Injection Molding
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Volume Rate, MVR At 280°C/5.0 Kg: 7
UL Recognized, 94HB Flame Class Rating (3): 1.5
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Noryl
Certification: COA/ICP Test/Rohs/MSDS
Model Number: EXNL0141
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic NoryL EXNL0141 resin is

"Noryl* EXNL0141 is an unfilled modified polyphenylene ether resin suitable for injection molding. Designed to possess a unique low gloss
surface appearance even when molded in polished tools, this resin uses non-chlorinated, non-brominated FR additives to achieve a V1"
"UL94 rating. Noryl EXNL0141 is available in colors and may be an excellent choice for a wide variety of applications including hand held
devises, housings and displays."




Property



TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 64 MPa ASTM D 638
Tensile Stress, brk, Type I, 50 mm/min 53 MPa ASTM D 638
Tensile Strain, yld, Type I, 50 mm/min 4.8 % ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 30 % ASTM D 638
Tensile Modulus, 5 mm/min 2300 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 97 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 2400 MPa ASTM D 790
Taber Abrasion, CS-17, 1 kg 60 mg/1000cy SABIC Method
Tensile Stress, yield, 50 mm/min 63 MPa ISO 527
Tensile Stress, break, 50 mm/min 52 MPa ISO 527
Tensile Strain, yield, 50 mm/min 4.6 % ISO 527
Tensile Strain, break, 50 mm/min 30 % ISO 527
Tensile Modulus, 1 mm/min 2350 MPa ISO 527
Flexural Stress, yield, 2 mm/min 92 MPa ISO 178
Flexural Modulus, 2 mm/min 2300 MPa ISO 178
Hardness, H358/30 105 MPa ISO 2039-1
Hardness, Rockwell R 119 - ISO 2039-2
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 120 J/m ASTM D 256
Izod Impact, notched, -30°C 70 J/m ASTM D 256
Instrumented Impact Total Energy, 23°C 41 J ASTM D 3763
Izod Impact, notched 80*10*4 +23°C 11 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 -30°C 7 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm 14 kJ/m² ISO 179/1eA
Charpy -30°C, V-notch Edgew 80*10*4 sp=62mm 7 kJ/m² ISO 179/1eA
THERMAL Value Unit Standard
Vicat Softening Temp, Rate B/50 137 °C ASTM D 1525
HDT, 0.45 MPa, 3.2 mm, unannealed 130 °C ASTM D 648
HDT, 1.82 MPa, 3.2mm, unannealed 116 °C ASTM D 648
CTE, -40°C to 40°C, flow 8.2E+01 1/°C ASTM E 831
CTE, -40°C to 40°C, xflow 8.5E+01 1/°C ASTM E 831
CTE, -40°C to 40°C, flow 8.2E+01 1/°C ISO 11359-2
CTE, -40°C to 40°C, xflow 8.5E+01 1/°C ISO 11359-2
Ball Pressure Test, 125°C +/- 2°C Passes - IEC 60695-10-2
Vicat Softening Temp, Rate B/50 135 °C ISO 306
Vicat Softening Temp, Rate B/120 138 °C ISO 306
HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm 130 °C ISO 75/Bf
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 115 °C ISO 75/Af
PHYSICAL Value Unit Standard
Specific Gravity 1.08 - ASTM D 792
Mold Shrinkage, flow, 3.2 mm 0.5 - 0.7 % SABIC Method
Melt Flow Rate, 280°C/5.0 kgf 7 g/10 min ASTM D 1238
Density 1.08 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.23 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.06 % ISO 62
Melt Volume Rate, MVR at 280°C/5.0 kg 7 cm³/10 min ISO 1133
OPTICAL Value Unit Standard
Gloss, untextured, 60 degrees 20 - ASTM D 523
FLAME CHARACTERISTICS Value Unit Standard
UL Recognized, 94V-1 Flame Class Rating (3) 1.5 mm UL 94
Glow Wire Flammability Index 960°C, passes at 3.2 mm IEC 60695-2-12
Glow Wire Ignitability Temperature, 3.0 mm 700 °C IEC 60695-2-13
Source GMD, last updated:01/05/2006

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 80 - 100 °C
Drying Time 2 - 3 hrs
Melt Temperature 280 - 300 °C
Nozzle Temperature 260 - 280 °C
Front - Zone 3 Temperature 280 - 300 °C
Middle - Zone 2 Temperature 260 - 280 °C
Rear - Zone 1 Temperature 240 - 260 °C
Hopper Temperature 60 - 80 °C
Mold Temperature 60 - 100 °C
Source GMD, last updated:01/05/2006

Other related products we recommend:

  • Drinking water / food grade:731,731S,GFN10F,GFN20F,GFN30F,GFN1520V,GFN1630V(Color requirements)

  • Unreinforce and flame retardant: 0150B,N190X,PX9406P,SE100X

  • Reinforce and flame retardant: SE1GFN1,SE1GFN2,SE1GFN3,HS2000X

 For more information please see below

Sabic Noryl EXNL0141 Is An Unfilled Modified Polyphenylene Ether Resin Suitable For Injection Molding 0   Sabic Noryl EXNL0141.pdf



Get The Latest Quotation

5000 kinds of products

1000 tons of spot inventory

First-level distribution source in South China

Reduce procurement costs, improve supply stability,

Help you find the most suitable engineering plastic materials

Sabic Noryl EXNL0141 Is An Unfilled Modified Polyphenylene Ether Resin Suitable For Injection Molding 1Click to consult and get the latest quotation within 24 hours!



Sabic Noryl EXNL0141 Is An Unfilled Modified Polyphenylene Ether Resin Suitable For Injection Molding 2



Sabic Noryl Resin Application



Sabic Noryl PPO is modified polyphenylene oxide (PPO) resins produced by the Sabic company. It is known for its excellent balance of properties, including high heat resistance, dimensional stability, and chemical resistance.



Noryl PPO resins are produced by blending PPO with other materials, such as polystyrene or polyamide.Sabic Noryl PPO include:
1. High heat resistance: Sabic Noryl PPO has a high heat deflection temperature.This makes it suitable for use in high-temperature applications, such as automotive engine parts and electrical components.
2. Dimensional stability: Sabic Noryl PPO has a low coefficient of thermal expansion. This makes it suitable for use in applications where precision and accuracy are important.



Sabic Lexan PC Application

3. Chemical resistance: Sabic Noryl PPO has good chemical resistance. It is commonly used in automotive and electrical applications where chemical resistance is important.
4. Good electrical properties: Sabic Noryl PPO has good electrical properties. This makes it suitable for use in electrical and electronic applications, such as connectors and switches.
5. Ease of processing: Sabic Noryl PPO is easy to process and can be easily molded into complex shapes with thin walls.
