Sabic Noryl EXNL0140 Thermoplastic Nonhalogenated Material For Automotive Wire Insulation

100KG
MOQ
*USD
Price
Sabic Noryl EXNL0140 Thermoplastic Nonhalogenated Material For Automotive Wire Insulation
Features Gallery Product Description Request A Quote
Features
Specifications
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Noryl
Certification: COA/ICP Test/Rohs/MSDS
Model Number: EXNL0140
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic NoryL EXNL0140 resin is

Thermoplastic, nonhalogenated material for automotive wire insulation class C




Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 43 MPa ASTM D 638
Tensile Stress, brk, Type I, 50 mm/min 41 MPa ASTM D 638
Tensile Strain, yld, Type I, 50 mm/min 9.7 % ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 62 % ASTM D 638
Tensile Modulus, 50 mm/min 1590 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 54 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 1560 MPa ASTM D 790
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 328 J/m ASTM D 256
THERMAL Value Unit Standard
HDT, 1.82 MPa, 3.2mm, unannealed 90 °C ASTM D 648
PHYSICAL Value Unit Standard
Specific Gravity 1.03 - ASTM D 792
Melt Flow Rate, 280°C/5.0 kgf 13.8 g/10 min ASTM D 1238
Source GMD, last updated:02/03/2005

Processing



Parameter
Wire Coating Extrusion Value Unit
Drying Temperature 40 - 80 °C
Drying Time 0 - 6 hrs
Drying Time (Cumulative) 8 hrs
Maximum Moisture Content 0.05 %
Screw Speed 5 - 50 rpm
Feed Zone Temperature 20 - 50 °C
Middle Zone Temperatures 230 - 250 °C
Head Zone Temperature 270 - 280 °C
Neck Temperature 270 - 280 °C
Cross-head Temperature 270 - 280 °C
Die Temperature 270 - 280 °C
Melt Temperature 270 - 285 °C
Conductor Pre-heat Temperature 20 - 100 °C
Screen Pack mesh 200 - 80 -
Cooling Water Air Gap 100 - 1000 mm
Water Bath Temperature 15 - 30 °C
Source GMD, last updated:02/03/2005

Other related products we recommend:

  • Drinking water / food grade:731,731S,GFN10F,GFN20F,GFN30F,GFN1520V,GFN1630V(Color requirements)

  • Unreinforce and flame retardant: 0150B,N190X,PX9406P,SE100X

  • Reinforce and flame retardant: SE1GFN1,SE1GFN2,SE1GFN3,HS2000X

 For more information please see below

Sabic Noryl EXNL0140 Thermoplastic Nonhalogenated Material For Automotive Wire Insulation 0    Sabic Noryl EXNL0140.pdf



Get The Latest Quotation

5000 kinds of products

1000 tons of spot inventory

First-level distribution source in South China

Reduce procurement costs, improve supply stability,

Help you find the most suitable engineering plastic materials

Sabic Noryl EXNL0140 Thermoplastic Nonhalogenated Material For Automotive Wire Insulation 1Click to consult and get the latest quotation within 24 hours!



Sabic Noryl EXNL0140 Thermoplastic Nonhalogenated Material For Automotive Wire Insulation 2



Sabic Noryl Resin Application



Sabic Noryl PPO is modified polyphenylene oxide (PPO) resins produced by the Sabic company. It is known for its excellent balance of properties, including high heat resistance, dimensional stability, and chemical resistance.



Noryl PPO resins are produced by blending PPO with other materials, such as polystyrene or polyamide.Sabic Noryl PPO include:
1. High heat resistance: Sabic Noryl PPO has a high heat deflection temperature.This makes it suitable for use in high-temperature applications, such as automotive engine parts and electrical components.
2. Dimensional stability: Sabic Noryl PPO has a low coefficient of thermal expansion. This makes it suitable for use in applications where precision and accuracy are important.



Sabic Lexan PC Application

3. Chemical resistance: Sabic Noryl PPO has good chemical resistance. It is commonly used in automotive and electrical applications where chemical resistance is important.
4. Good electrical properties: Sabic Noryl PPO has good electrical properties. This makes it suitable for use in electrical and electronic applications, such as connectors and switches.
5. Ease of processing: Sabic Noryl PPO is easy to process and can be easily molded into complex shapes with thin walls.
