S-Plastics PC 500ECR Description
* 500ECR Polycarbonate (PC) resin is a 10% glass fiber filled, injection moldable grade. It is of non-chlorinated & non-brominated flame retardant systems with UL-94 V0 rating at 2.3mm. It is available in various opaque color options designed for applications requiring improved stiffness.
S-Plastics PC 500ECR Characteristic
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 66 | MPa | ASTM D 638 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 3440 | MPa | ASTM D 790 |
| Hardness, Rockwell M | 85 | - | ASTM D 785 |
| Hardness, Rockwell R | 124 | - | ASTM D 785 |
| Taber Abrasion, CS-17, 1 kg | 11 | mg/1000cy | ASTM D 1044 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 2136 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 106 | J/m | ASTM D 256 |
| Tensile Impact, Type "S" | 157 | kJ/m² | ASTM D 1822 |
| Falling Dart Impact (D 3029), 23°C | 101 | J | ASTM D 3029 |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/50 | 154 | °C | ASTM D 1525 |
| HDT, 0.45 MPa, 6.4 mm, unannealed | 146 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 142 | °C | ASTM D 648 |
| Relative Temp Index, Elec | 130 | °C | UL 746B |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.27 | - | ASTM D 792 |
| Specific Volume | 0.8 | cm³/g | ASTM D 792 |
| Density | 1.245 | g/cm³ | ASTM D 792 |
| ELECTRICAL | Value | Unit | Standard |
| Volume Resistivity | >1.E+17 | Ohm-cm | ASTM D 257 |
| Dielectric Strength, in air, 3.2 mm | 17.7 | kV/mm | ASTM D 149 |
| Relative Permittivity, 1 MHz | 3.05 | - | ASTM D 150 |
| Dissipation Factor, 50/60 Hz | 0.0008 | - | ASTM D 150 |
|
For more information please see below |
|
|
S-Plastics 500ECR.pdf |
|
Get The Latest Quotation 5000 kinds of products 1000 tons of spot inventory First-level distribution source in South China Reduce procurement costs, improve supply stability, Help you find the most suitable engineering plastic materials
|
|
S-Plastics PC Application
|
S-Plastics PC is a family of polycarbonate (PC) resins produced by the S-Plastics company. S-Plastics PC comes in a range of grades that are designed for different applications. S-Plastics PC is known for its excellent mechanical properties, including high impact resistance, dimensional stability, and toughness. It also has good chemical resistance, making it suitable for use in harsh environments where it may be exposed to chemicals or other corrosive substances. |
|
