Product Description

Sabic Lexan  194 resin is Nonhalogenated. 8.5 MFR. High impact. Thick wall sections. Opaques only. FDA food contact compliant in limited colors.



Property

TYPICAL PROPERTIES (1)
MECHANICALValueUnitStandard
Tensile Stress, yld, Type I, 50 mm/min58MPaASTM D 638
Tensile Stress, brk, Type I, 50 mm/min63MPaASTM D 638
Tensile Strain, yld, Type I, 50 mm/min7%ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min115%ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span81MPaASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span2130MPaASTM D 790
Hardness, Rockwell M68-ASTM D 785
Hardness, Rockwell R118-ASTM D 785
Taber Abrasion, CS-17, 1 kg20mg/1000cyASTM D 1044
IMPACTValueUnitStandard
Izod Impact, unnotched, 23°C3204J/mASTM D 4812
Izod Impact, notched, 23°C747J/mASTM D 256
Tensile Impact, Type "S"420kJ/m²ASTM D 1822
Falling Dart Impact (D 3029), 23°C169JASTM D 3029
THERMALValueUnitStandard
HDT, 0.45 MPa, 6.4 mm, unannealed137°CASTM D 648
HDT, 1.82 MPa, 6.4 mm, unannealed126°CASTM D 648
CTE, -40°C to 95°C, flow6.48E-051/°CASTM E 831
PHYSICALValueUnitStandard
Specific Gravity1.19-ASTM D 792
Specific Volume0.84cm³/gASTM D 792
Water Absorption, 24 hours0.19%ASTM D 570
Water Absorption, equilibrium, 23C0.37%ASTM D 570
Water Absorption, equilibrium, 100°C0.54%ASTM D 570
Mold Shrinkage, flow, 3.2 mm0.5 - 0.7%SABIC Method
Melt Flow Rate, 300°C/1.2 kgf8.5g/10 minASTM D 1238
ELECTRICALValueUnitStandard
Volume Resistivity2.5E+17Ohm-cmASTM D 257
Dielectric Strength, in air, 3.2 mm16.3kV/mmASTM D 149
Relative Permittivity, 1 MHz3-ASTM D 150
Dissipation Factor, 50/60 Hz0.0009-ASTM D 150
Dissipation Factor, 1 MHz0.01-ASTM D 150
Source GMD, last updated:01/03/2006

Processing

Parameter
Injection MoldingValueUnit
Drying Temperature120°C
Drying Time3 - 4hrs
Drying Time (Cumulative)48hrs
Maximum Moisture Content0.02%
Melt Temperature310 - 330°C
Nozzle Temperature305 - 325°C
Front - Zone 3 Temperature310 - 330°C
Middle - Zone 2 Temperature300 - 320°C
Rear - Zone 1 Temperature290 - 310°C
Mold Temperature80 - 115°C
Back Pressure0.3 - 0.7MPa
Screw Speed40 - 70rpm
Shot to Cylinder Size40 - 60%
Vent Depth0.025 - 0.076mm
Source GMD, last updated:01/03/2006
