Sabic Thermocomp MK0049A is a compound based on Polypropylene resin containing Talc, Flame Retardant. Added features i

100KG
MOQ
*USD
Price
Sabic Thermocomp MK0049A  is a compound based on Polypropylene resin containing Talc, Flame Retardant. Added features i
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Volume Rate, MVR At 260°C/2.16 Kg: ???
UL Recognized, 94HB Flame Class Rating (3): ???
High Light:

Thermocomp Sabic Thermocomp

,

Sabic Sabic Thermocomp

Basic Infomation
Place of Origin: ——
Brand Name: Sabic Thermocomp
Certification: COA/ICP Test/Rohs/MSDS
Model Number: MK0049A
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Thermocomp MK0049A resin is a compound based on Polypropylene resin containing Talc, Flame Retardant. Added features include :


Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yield, 50 mm/min 22 MPa ISO 527
Tensile Stress, break, 50 mm/min 19 MPa ISO 527
Tensile Strain, yield, 50 mm/min 2.6 % ISO 527
Tensile Modulus, 1 mm/min 2600 MPa ISO 527
Flexural Stress, yield, 2 mm/min 37 MPa ISO 178
Flexural Modulus, 2 mm/min 2900 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, unnotched 80*10*4 +23°C 15 kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 4 kJ/m² ISO 180/1A
THERMAL Value Unit Standard
CTE, 23°C to 60°C, flow 8.2E-05 1/°C ISO 11359-2
CTE, 23°C to 60°C, xflow 1.28E-04 1/°C ISO 11359-2
HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm 115 °C ISO 75/Bf
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 67 °C ISO 75/Af
PHYSICAL Value Unit Standard
Mold Shrinkage, flow 1.1 % SABIC Method
Density 1.35 g/cm³ ISO 1183
Water Absorption, 23°C/24hrs 0.01 % ISO 62-1
FLAME CHARACTERISTICS Value Unit Standard
UL Compliant, 94V-0 Flame Class Rating (3)(4) 1.6 mm UL 94 by GE
Source GMD, last updated:03/14/2008

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 70 °C
Drying Time 4 hrs
Melt Temperature 170 - 190 °C
Front - Zone 3 Temperature 180 - 190 °C
Middle - Zone 2 Temperature 170 - 180 °C
Rear - Zone 1 Temperature 160 - 170 °C
Mold Temperature 30 - 50 °C
Back Pressure 0.2 - 0.3 MPa
Screw Speed 25 - 50 rpm
Source GMD, last updated:03/14/2008
