Product Description

Sabic Lexan  PPC4704resin is High heat resistant polycarbonate copolymer, provides DTUL of 300F at 264 psi. FDA food contact compliant in limited colors. EffectiveJanuary 15th, 2008 this grade will no longer be supported with biocompatibility information and should not be used for medicalapplications which require biocompatibility. Alternative grade HPH4704.




Property

MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 65 MPa ASTM D 638
Tensile Stress, brk, Type I, 50 mm/min 77 MPa ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 78 % ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 97 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 2330 MPa ASTM D 790
Hardness, Rockwell M 92 - ASTM D 785
Hardness, Rockwell R 127 - ASTM D 785
IMPACT Value Unit Standard
Izod Impact, unnotched, 23°C 3204 J/m ASTM D 4812
Izod Impact, notched, 23°C 373 J/m ASTM D 256
Tensile Impact, Type "S" 577 kJ/m² ASTM D 1822
Falling Dart Impact (D 3029), 23°C 149 J ASTM D 3029
THERMAL Value Unit Standard
HDT, 1.82 MPa, 3.2mm, unannealed 148 °C ASTM D 648
CTE, -40°C to 95°C, flow 8.1E-05 1/°C ASTM E 831
Specific Heat 1.25 J/g-°C ASTM C 351
Thermal Conductivity 0.21 W/m-°C ASTM C 177
Relative Temp Index, Elec 130 °C UL 746B
Relative Temp Index, Mech w/impact 130 °C UL 746B
Relative Temp Index, Mech w/o impact 130 °C UL 746B
PHYSICAL Value Unit Standard
Specific Gravity 1.2 - ASTM D 792
Specific Volume 0.83 cm³/g ASTM D 792
Density 1.19 g/cm³ ASTM D 792
Water Absorption, 24 hours 0.19 % ASTM D 570
Mold Shrinkage, flow, 3.2 mm 0.8 - 1 % SABIC Method
Melt Flow Rate, 300°C/1.2 kgf 2 g/10 min ASTM D 1238
OPTICAL Value Unit Standard
Light Transmission 85 % ASTM D 1003
Haze 1 % ASTM D 1003
Refractive Index 1.6 - ASTM D 542
ELECTRICAL Value Unit Standard
Volume Resistivity >2.5E+17 Ohm-cm ASTM D 257
Dielectric Strength, in air, 3.2 mm 20 kV/mm ASTM D 149
Relative Permittivity, 50/60 Hz 3.27 - ASTM D 150
Relative Permittivity, 1 MHz 3.1 - ASTM D 150
Dissipation Factor, 50/60 Hz 0.0016 - ASTM D 150
Dissipation Factor, 100 Hz 0.026 - ASTM D 150
Arc Resistance, Tungsten {PLC} 6 PLC Code ASTM D 495
Hot Wire Ignition {PLC) 2 PLC Code UL 746A
High Voltage Arc Track Rate {PLC} 3 PLC Code UL 746A
High Ampere Arc Ign, surface {PLC} 3 PLC Code UL 746A
Comparative Tracking Index (UL) {PLC} 3 PLC Code UL 746A
FLAME CHARACTERISTICS Value Unit Standard
UL Recognized, 94HB Flame Class Rating (3) 1.47 mm UL 94
Source GMD, last updated:01/03/2006

Processing

(1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours
storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded
samples. All samples tested under ISO test standards are prepared according to ISO 294.
(2) Only typical data for selection purposes. Not to be used for part or tool design.
(3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions.
(4) Internal measurements according to UL standards.
