Sabic Lexan LS2FX UV stabilized PC. Edge Glow Visual Effect in automotive lens applications. Medium viscosity (11.0 MFR)

100KG
MOQ
*USD
Price
Sabic Lexan LS2FX UV stabilized PC. Edge Glow Visual Effect in automotive lens applications. Medium viscosity (11.0 MFR)
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Flow Rate, 300°C/1.2 Kgf: 11
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Lexan
Certification: COA/ICP Test/Rohs/MSDS
Model Number: LS2FX
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Lexan LS2FX resin is UV stabilized PC. Edge Glow Visual Effect in automotive lens applications. Medium viscosity (11.0 MFR). Transparent colors.



Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 62 MPa ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 130 % ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 96 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 2340 MPa ASTM D 790
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 801 J/m ASTM D 256
Tensile Impact, Type "S" 577 kJ/m² ASTM D 1822
Falling Dart Impact, 23°C 169 J SABIC Method
Instrumented Impact Energy @ peak, 23°C 63 J ASTM D 3763
THERMAL Value Unit Standard
HDT, 1.82 MPa, 6.4 mm, unannealed 132 °C ASTM D 648
PHYSICAL Value Unit Standard
Specific Gravity 1.2 - ASTM D 792
Water Absorption, 24 hours 0.15 % ASTM D 570
Mold Shrinkage, flow, 3.2 mm 0.5 - 0.7 % SABIC Method
Melt Flow Rate, 300°C/1.2 kgf 11 g/10 min ASTM D 1238
OPTICAL Value Unit Standard
Light Transmission 88 % ASTM D 1003
Source GMD, last updated:03/12/2003

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 3 - 4 hrs
Drying Time (Cumulative) 48 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 295 - 315 °C
Nozzle Temperature 290 - 310 °C
Front - Zone 3 Temperature 295 - 315 °C
Middle - Zone 2 Temperature 280 - 305 °C
Rear - Zone 1 Temperature 270 - 295 °C
Mold Temperature 70 - 95 °C
Back Pressure 0.3 - 0.7 MPa
Screw Speed 40 - 70 rpm
Shot to Cylinder Size 40 - 60 %
Vent Depth 0.025 - 0.076 mm
Source GMD, last updated:03/12/2003






For more information please download the datasheet

Sabic Lexan LS2FX UV stabilized PC. Edge Glow Visual Effect in automotive lens applications. Medium viscosity (11.0 MFR) 0  Sabic Lexan LS2FX.pdf
