Sabic Lexan ML7676 Is A Flame Retardant Polycarbonate Featurning Good Impact Performance With Balanced Flow

100KG
MOQ
*USD
Price
Sabic Lexan ML7676 Is A Flame Retardant Polycarbonate Featurning Good Impact Performance With Balanced Flow
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Flow Rate, 300°C/1.2 Kgf: 16
UL Recognized, 94V-2 Flame Class Rating (3): 1.5
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Lexan
Certification: COA/ICP Test/Rohs/MSDS
Model Number: ML7676
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Lexan  ML7676 resin is  a flame retardant polycarbonate featurning good impact performance with balanced flow and heatproperties. It is of non brominated and non chlorinated flame retardant systems with UL-94 V0 listed at 1.5mm.




Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 56 MPa ASTM D 638
Tensile Stress, brk, Type I, 50 mm/min 58 MPa ASTM D 638
Tensile Strain, yld, Type I, 50 mm/min 6 % ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 117 % ASTM D 638
Tensile Modulus, 5 mm/min 2100 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 92 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 2200 MPa ASTM D 790
Tensile Stress, yield, 50 mm/min 56 MPa ISO 527
Tensile Stress, break, 50 mm/min 57 MPa ISO 527
Tensile Strain, yield, 50 mm/min 6 % ISO 527
Tensile Strain, break, 50 mm/min 108 % ISO 527
Flexural Stress, yield, 2 mm/min 87 MPa ISO 178
Flexural Modulus, 2 mm/min 2100 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 670 J/m ASTM D 256
Izod Impact, notched, -30°C 558 J/m ASTM D 256
Izod Impact, unnotched 80*10*3 +23°C NB kJ/m² ISO 180/1U
Izod Impact, unnotched 80*10*3 -30°C NB kJ/m² ISO 180/1U
Izod Impact, notched 80*10*3 +23°C 65 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*3 -30°C 30 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*3 sp=62mm 70 kJ/m² ISO 179/1eA
Charpy -30°C, V-notch Edgew 80*10*3 sp=62mm 35 kJ/m² ISO 179/1eA
Charpy 23°C, Unnotch Edgew 80*10*3 sp=62mm NB kJ/m² ISO 179/1eU
Charpy -30°C, Unnotch Edgew 80*10*3 sp=62mm NB kJ/m² ISO 179/1eU
THERMAL Value Unit Standard
Vicat Softening Temp, Rate B/50 140 °C ASTM D 1525
HDT, 1.82 MPa, 3.2mm, unannealed 123 °C ASTM D 648
CTE, -40°C to 40°C, flow 6.1E-05 1/°C ASTM E 831
CTE, -40°C to 40°C, xflow 6.2E-05 1/°C ASTM E 831
CTE, -40°C to 40°C, flow 6.1E-05 1/°C ISO 11359-2
CTE, -40°C to 40°C, xflow 6.2E-05 1/°C ISO 11359-2
Vicat Softening Temp, Rate B/50 139 °C ISO 306
Vicat Softening Temp, Rate B/120 141 °C ISO 306
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 118 °C ISO 75/Af
Relative Temp Index, Elec 125 °C UL 746B
Relative Temp Index, Mech w/impact 115 °C UL 746B
Relative Temp Index, Mech w/o impact 120 °C UL 746B
PHYSICAL Value Unit Standard
Specific Gravity 1.19 - ASTM D 792
Mold Shrinkage, flow, 3.2 mm 0.4 - 0.8 % SABIC Method
Melt Flow Rate, 300°C/1.2 kgf 16 g/10 min ASTM D 1238
Density 1.19 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.4 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.15 % ISO 62
Melt Volume Rate, MVR at 300°C/1.2 kg 15 cm³/10 min ISO 1133
FLAME CHARACTERISTICS Value Unit Standard
UL Compliant, 94V-0 Flame Class Rating (3)(4) 1.5 mm UL 94 by GE
Source GMD, last updated:05/05/2008

Processing

THESE PROPERTY VALUES ARE NOT INTENDED FOR SPECIFICATION PURPOSES.
PLEASE CHECK WITH YOUR (LOCAL SALES OFFICE) FOR AVAILABILITY IN YOUR REGION
(1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours
storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded
samples. All samples tested under ISO test standards are prepared according to ISO 294.
(2) Only typical data for selection purposes. Not to be used for part or tool design.
(3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions.
(4) Internal measurements according to UL standards.
