Sabic Lexan ML7672 Non FR PC + GF, UV-Stabilizer, Balanced Flow & Impact. Available In Opaque Only.

100KG
MOQ
*USD
Price
Sabic Lexan ML7672 Non FR PC + GF, UV-Stabilizer, Balanced Flow & Impact. Available In Opaque Only.
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Flow Rate, 300°C/1.2 Kgf: 4.5
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Lexan
Certification: COA/ICP Test/Rohs/MSDS
Model Number: ML7672
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Lexan  ML7672 resin is Non FR PC + GF, UV-Stabilizer, balanced flow & impact. Available in Opaque only.




Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, brk, Type I, 5 mm/min 52 MPa ASTM D 638
Tensile Strain, brk, Type I, 5 mm/min 5 % ASTM D 638
Tensile Modulus, 5 mm/min 5200 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 99 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 4860 MPa ASTM D 790
Tensile Stress, yield, 5 mm/min 11 MPa ISO 527
Tensile Stress, break, 5 mm/min 57 MPa ISO 527
Tensile Strain, yield, 5 mm/min 0.3 % ISO 527
Tensile Strain, break, 5 mm/min 1.8 % ISO 527
Tensile Modulus, 1 mm/min 5630 MPa ISO 527
Flexural Stress, yield, 2 mm/min 100 MPa ISO 178
Flexural Modulus, 2 mm/min 5480 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 240 J/m ASTM D 256
Instrumented Impact Total Energy, 23°C 28 J ASTM D 3763
Izod Impact, notched 80*10*4 +23°C 18 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm 19 kJ/m² ISO 179/1eA
THERMAL Value Unit Standard
Vicat Softening Temp, Rate B/50 143 °C ASTM D 1525
HDT, 1.82 MPa, 3.2mm, unannealed 138 °C ASTM D 648
CTE, -40°C to 40°C, flow 2.7E-05 1/°C ASTM E 831
CTE, -40°C to 40°C, xflow 6.9E-05 1/°C ASTM E 831
CTE, -40°C to 40°C, flow 2.7E-05 1/°C ISO 11359-2
CTE, -40°C to 40°C, xflow 6.9E-05 1/°C ISO 11359-2
Vicat Softening Temp, Rate B/50 143 °C ISO 306
Vicat Softening Temp, Rate B/120 145 °C ISO 306
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 140 °C ISO 75/Af
PHYSICAL Value Unit Standard
Specific Gravity 1.33 - ASTM D 792
Mold Shrinkage, flow, 3.2 mm 0.2 - 0.6 % SABIC Method
Melt Flow Rate, 300°C/1.2 kgf 4.5 g/10 min ASTM D 1238
Density 1.33 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.2 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.3 % ISO 62
Melt Volume Rate, MVR at 300°C/1.2 kg 5 cm³/10 min ISO 1133
Source GMD, last updated:01/12/2008

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 3 - 4 hrs
Drying Time (Cumulative) 48 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 315 - 340 °C
Nozzle Temperature 310 - 330 °C
Front - Zone 3 Temperature 315 - 340 °C
Middle - Zone 2 Temperature 305 - 325 °C
Rear - Zone 1 Temperature 295 - 315 °C
Mold Temperature 80 - 115 °C
Back Pressure 0.3 - 0.7 MPa
Screw Speed 40 - 70 rpm
Shot to Cylinder Size 40 - 60 %
Vent Depth 0.025 - 0.076 mm
Source GMD, last updated:01/12/2008
THESE PROPERTY VALUES ARE NOT INTENDED FOR SPECIFICATION PURPOSES.
PLEASE CHECK WITH YOUR (LOCAL SALES OFFICE) FOR AVAILABILITY IN YOUR REGION
(1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours
storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded
samples. All samples tested under ISO test standards are prepared according to ISO 294.
(2) Only typical data for selection purposes. Not to be used for part or tool design.
(3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions.
(4) Internal measurements according to UL standards.
