Sabic Lexan LR120 a Polycarbonate grade with a low viscosity, suitable for small injection moulded parts.

100KG
MOQ
*USD
Price
Sabic Lexan LR120 a Polycarbonate grade with a low viscosity, suitable for small injection moulded parts.
Features Gallery Product Description Request A Quote
Features
Specifications
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Lexan
Certification: COA/ICP Test/Rohs/MSDS
Model Number: LR120
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Lexan  LR120 resin is a Polycarbonate grade with a low viscosity, suitable for small injection moulded parts. The product is designed to utilize selected recycle materials from our plants, customers and post consumer materials and


Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, yield, 50 mm/min 60 MPa ISO 527
Tensile Stress, break, 50 mm/min 60 MPa ISO 527
Tensile Strain, yield, 50 mm/min 6 % ISO 527
Tensile Strain, break, 50 mm/min 100 % ISO 527
Tensile Modulus, 1 mm/min 2350 MPa ISO 527
Flexural Stress, yield, 2 mm/min 90 MPa ISO 178
Flexural Modulus, 2 mm/min 2300 MPa ISO 178
Hardness, H358/30 95 MPa ISO 2039-1
IMPACT Value Unit Standard
Izod Impact, unnotched 80*10*4 +23°C NB kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 12 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm 11 kJ/m² ISO 179/1eA
Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm NB kJ/m² ISO 179/1eU
THERMAL Value Unit Standard
CTE, 23°C to 80°C, xflow 7.5E-05 1/°C ISO 11359-2
Vicat Softening Temp, Rate B/120 140 °C ISO 306
HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm 123 °C ISO 75/Ae
PHYSICAL Value Unit Standard
Mold Shrinkage on Tensile Bar, flow (2) (5) 0.5 - 0.7 % SABIC Method
Density 1.2 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.35 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.15 % ISO 62
Melt Volume Rate, MVR at 300°C/1.2 kg 18 cm³/10 min ISO 1133
ELECTRICAL Value Unit Standard
Surface Resistivity, ROA >1.E+15 Ohm IEC 60093
Dielectric Strength, in oil, 3.2 mm 16 kV/mm IEC 60243-1
Source GMD, last updated:1996/08/07

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 2 - 4 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 280 - 300 °C
Nozzle Temperature 270 - 290 °C
Front - Zone 3 Temperature 280 - 300 °C
Middle - Zone 2 Temperature 270 - 290 °C
Rear - Zone 1 Temperature 260 - 280 °C
Hopper Temperature 60 - 80 °C
Mold Temperature 80 - 100 °C
Source GMD, last updated:1996/08/07



For more information please download the datasheet

Sabic Lexan LR120 a Polycarbonate grade with a low viscosity, suitable for small injection moulded parts. 0  Sabic Lexan LR120.pdf
