Sabic Lexan BE2130 FOR EXISTING APPLICATIONS ONLY. High Flow, Excellent Flame Rating, Standard Gloss. Durable, Good Cost
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Flow Rate, 300°C/1.2 Kgf: 25
UL Recognized, 94V-2 Flame Class Rating (3): 1.47
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Lexan
Certification: COA/ICP Test/Rohs/MSDS
Model Number: BE2130
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Lexan  BE2130 resin is FOR EXISTING APPLICATIONS ONLY. High flow, excellent flame rating, standard gloss. Durable, good cost-to- performance balance.



Property

TYPICAL PROPERTIES (1)
MECHANICALValueUnitStandard
Tensile Stress, yld, Type I, 50 mm/min62MPaASTM D 638
Tensile Stress, brk, Type I, 50 mm/min49MPaASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span93MPaASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span2200MPaASTM D 790
IMPACTValueUnitStandard
Izod Impact, notched, 23°C267J/mASTM D 256
Gardner, 23°C9JASTM D 3029
Instrumented Impact Energy @ peak, 23°C47JASTM D 3763
THERMALValueUnitStandard
HDT, 1.82 MPa, 6.4 mm, unannealed129°CASTM D 648
Relative Temp Index, Elec125°CUL 746B
Relative Temp Index, Mech w/impact110°CUL 746B
Relative Temp Index, Mech w/o impact125°CUL 746B
PHYSICALValueUnitStandard
Specific Gravity1.21-ASTM D 792
Mold Shrinkage, flow, 3.2 mm0.6 - 0.8%SABIC Method
Melt Flow Rate, 300°C/1.2 kgf25g/10 minASTM D 1238
OPTICALValueUnitStandard
Gloss, untextured, 60 degrees90-ASTM D 523
Gloss, textured, 60 deg, MT-1055-214-ASTM D 523
ELECTRICALValueUnitStandard
Arc Resistance, Tungsten {PLC}7PLC CodeASTM D 495
Hot Wire Ignition {PLC)2PLC CodeUL 746A
High Voltage Arc Track Rate {PLC}4PLC CodeUL 746A
High Ampere Arc Ign, surface {PLC}3PLC CodeUL 746A
Comparative Tracking Index (UL) {PLC}2PLC CodeUL 746A
FLAME CHARACTERISTICSValueUnitStandard
UL Recognized, 94V-0 Flame Class Rating (3)1.47mmUL 94
UL Recognized, 94-5VA Rating (3)2.99mmUL 94
Source GMD, last updated:01/09/2003

Processing

Parameter
Injection MoldingValueUnit
Drying Temperature120°C
Drying Time3 - 4hrs
Drying Time (Cumulative)48hrs
Maximum Moisture Content0.02%
Melt Temperature270 - 295°C
Nozzle Temperature265 - 290°C
Front - Zone 3 Temperature270 - 295°C
Middle - Zone 2 Temperature260 - 280°C
Rear - Zone 1 Temperature250 - 270°C
Mold Temperature70 - 95°C
Back Pressure0.3 - 0.7MPa
Screw Speed40 - 70rpm
Shot to Cylinder Size40 - 60%
Vent Depth0.025 - 0.076mm
Source GMD, last updated:01/09/2003






For more information please download the datasheet

Sabic Lexan BE2130 FOR EXISTING APPLICATIONS ONLY. High Flow, Excellent Flame Rating, Standard Gloss. Durable, Good Cost 0 Sabic Lexan BE2130.pdf
