Sabic Lexan FXG1413T"PC-Siloxane Copolymer In Special ""Diamond Sparkle"" Colors. Medium Flow. Improved Toughness

100KG
MOQ
*USD
Price
Sabic Lexan FXG1413T"PC-Siloxane Copolymer In Special ""Diamond Sparkle"" Colors. Medium Flow. Improved Toughness
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Flow Rate, 300°C/1.2 Kgf: 10
Basic Infomation
Place of Origin: ——
Brand Name: Sabic Lexan
Certification: COA/ICP Test/Rohs/MSDS
Model Number: FXG1413T
Payment & Shipping Terms
Packaging Details: 25KG/BAG
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

Sabic Lexan FXG1413T resin isPC-siloxane copolymer in special "Diamond Sparkle" colors. Medium flow. Improved toughness compared to medium flow standard PC in same color. Color package may affect performance.


Property

MECHANICAL Value Unit Standard
Tensile Stress, yld, Type I, 50 mm/min 59 MPa ASTM D 638
Tensile Stress, brk, Type I, 50 mm/min 47 MPa ASTM D 638
Tensile Strain, yld, Type I, 50 mm/min 6 % ASTM D 638
Tensile Strain, brk, Type I, 50 mm/min 69 % ASTM D 638
Tensile Modulus, 50 mm/min 2270 MPa ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 85 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 2270 MPa ASTM D 790
Tensile Stress, yield, 50 mm/min 57 MPa ISO 527
Tensile Stress, break, 50 mm/min 46 MPa ISO 527
Tensile Strain, yield, 50 mm/min 5.6 % ISO 527
Tensile Strain, break, 50 mm/min 38 % ISO 527
Tensile Modulus, 1 mm/min 2330 MPa ISO 527
Flexural Stress, yield, 2 mm/min 90 MPa ISO 178
Flexural Modulus, 2 mm/min 2190 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, notched, 23°C 570 J/m ASTM D 256
Izod Impact, notched, -30°C 376 J/m ASTM D 256
Instrumented Impact Total Energy, 23°C 54 J ASTM D 3763
Izod Impact, notched 80*10*4 +23°C 36 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 -30°C 16 kJ/m² ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm 19 kJ/m² ISO 179/1eA
THERMAL Value Unit Standard
Vicat Softening Temp, Rate B/50 142 °C ASTM D 1525
HDT, 1.82 MPa, 3.2mm, unannealed 123 °C ASTM D 648
CTE, -40°C to 95°C, flow 7.15E-05 1/°C ASTM E 831
CTE, -40°C to 95°C, xflow 7.93E-05 1/°C ASTM E 831
CTE, 23°C to 80°C, flow 7.15E-05 1/°C ISO 11359-2
CTE, 23°C to 80°C, xflow 7.93E-05 1/°C ISO 11359-2
Ball Pressure Test, 75°C +/- 2°C PASS - IEC 60695-10-2
Vicat Softening Temp, Rate B/50 141 °C ISO 306
Vicat Softening Temp, Rate B/120 143 °C ISO 306
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 119 °C ISO 75/Af
PHYSICAL Value Unit Standard
Specific Gravity 1.18 - ASTM D 792
Mold Shrinkage on Tensile Bar, flow (2) 0.4 - 0.8 % SABIC Method
Mold Shrinkage, flow, 3.2 mm 0.4 - 0.8 % SABIC Method
Mold Shrinkage, xflow, 3.2 mm 0.4 - 0.8 % SABIC Method
Melt Flow Rate, 300°C/1.2 kgf 10 g/10 min ASTM D 1238
Density 1.18 g/cm³ ISO 1183
Water Absorption, (23°C/sat) 0.12 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.09 % ISO 62
Melt Volume Rate, MVR at 300°C/1.2 kg 9 cm³/10 min ISO 1133
Source GMD, last updated:04/12/2004

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 3 - 4 hrs
Drying Time (Cumulative) 48 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 295 - 315 °C
Nozzle Temperature 290 - 310 °C
Front - Zone 3 Temperature 295 - 315 °C
Middle - Zone 2 Temperature 280 - 305 °C
Rear - Zone 1 Temperature 215 - 295 °C
Mold Temperature 70 - 95 °C
Back Pressure 0.3 - 0.7 MPa
Screw Speed 40 - 70 rpm
Shot to Cylinder Size 40 - 60 %
Vent Depth 0.025 - 0.076 mm
Source GMD, last updated:04/12/2004






For more information please download the datasheet

Sabic Lexan FXG1413T"PC-Siloxane Copolymer In Special ""Diamond Sparkle"" Colors. Medium Flow. Improved Toughness 0  Sabic Lexan FXG1413T.pdf
